Dome Head Blind Rivets
| Rivet Size | Diameter | Length | Grip Range | Drill Bit Size |
| 3-2 | 2.4mm or 3/32" |
6.0mm | 3.2mm | 3/32" or Jobber 2.5mm |
| 3-3 | 8.0mm | 4.8mm | ||
| 3-4 | 9.0mm | 6.4mm | ||
| 4-1 | 3.2mm or 1/8" |
4.8mm | 1.6mm | 1/8" or Jobber 3.3mm or No. 30 |
| 4-2 | 6.4mm | 3.2mm | ||
| 4-3 | 8.0mm | 4.8mm | ||
| 4-4 | 9.6mm | 6.4mm | ||
| 4-5 | 11.5mm | 8.0mm | ||
| 4-6 | 12.7mm | 9.5mm | ||
| 4-7 | 15.0mm | 11.0mm | ||
| 4-8 | 16.1mm | 12.7mm | ||
| 4-9 | 18.6mm | 14.2mm | ||
| 4-10 | 19.1mm | 16.0mm | ||
| 4-12 | 25.0mm | 19.0mm | ||
| 5-1 | 4.0mm or 5/32" |
5.8mm | 1.6mm | 5/32" or Jobber 4.1mm or No. 20 |
| 5-2 | 7.0mm | 3.2mm | ||
| 5-3 | 8.5mm | 4.8mm | ||
| 5-4 | 10.0mm | 6.4mm | ||
| 5-5 | 11.4mm | 8.0mm | ||
| 5-6 | 13.0mm | 9.6mm | ||
| 5-7 | 15.5mm | 11.0mm | ||
| 5-8 | 16.5mm | 12.7mm | ||
| 5-9 | 18.6mm | 15.0mm | ||
| 5-10 | 19.5mm | 16.0mm | ||
| 5-12 | 24.0mm | 19.0mm | ||
| 6-1 | 4.8mm or 3/16" |
6.4mm | 1.6mm | 3/16" or Jobber 4.9mm or No. 11 |
| 6-2 | 7.5mm | 3.2mm | ||
| 6-3 | 9.6mm | 4.8mm | ||
| 6-4 | 11.0mm | 6.4mm | ||
| 6-5 | 12.7mm | 8.0mm | ||
| 6-6 | 14.5mm | 9.5mm | ||
| 6-7 | 16.2mm | 11.0mm | ||
| 6-8 | 17.5mm | 12.7mm | ||
| 6-9 | 19.0mm | 15.0mm | ||
| 6-10 | 20.4mm | 16.0mm | ||
| 6-11 | 22.5mm | 18.1mm | ||
| 6-12 | 25.0mm | 19.0mm | ||
| 6-14 | 27.4mm | 22.2mm | ||
| 6-16 | 31.0mm | 25.4mm | ||
| 6-20 | 38.0mm | 31.8mm | ||
| 6-22 | 40.0mm | 33.8mm | ||
| 6-25 | 44.0mm | 37.8mm | ||
| 8-2 | 6.5mm or 1/4" |
7.5mm | 3.2mm | 1/4" or Jobber 6.5mm |
| 8-4 | 11.0mm | 6.4mm | ||
| 8-6 | 14.5mm | 9.5mm | ||
| 8-8 | 17.5mm | 12.7mm | ||
| 8-10 | 20.4mm | 16.0mm | ||
| 8-12 | 25.0mm | 19.0mm | ||
| 8-16 | 31.0mm | 25.4mm |
Multi Grip Rivets
| Rivet Size | Diameter | Length | Grip Range | Drill Bit Size |
| 4-3 | 3.2mm or 1/8" |
8.0mm | 1.0mm - 4.8mm | 1/8" or Jobber 3.3mm or No. 30 |
| 5-4 | 4.0mm or 5/32" |
10.0mm | 1.6mm - 6.4mm | 5/32" or Jobber 4.1mm or No. 20 |
| 5-6 | 12.0mm | 4.8mm - 9.6mm | ||
| 6-6 | 4.8mm or 3/16" |
14.3mm | 3.2mm - 9.6mm | 3/16" or Jobber 4.9mm or No. 11 |
| 6-8 | 17.5mm | 8.0mm - 12.7mm | ||
| 6-12 | 25.0mm | 11.2mm - 19.1mm |
